T60 Model - 5/16'' or 3/8" Clip Mount
Moisture Resistant Thermostat
These automatic reset sealed thermostats were designed for humid and moisture environments.
Description
The SEO (T) series automatic reset thermostat offers a moisture resistant fully encapsulated design. A resin filled thermoplastic cap covers the thermostat. The snap-action auto reset bi-metal disc has a fixed factory calibrated setting that is located adjacent to the surface. This will provide a rapid response to temperature change.
Specifications
| Series | Encapsulated |
|---|---|
| Type | Automatic Reset - Encapsulated |
| Function | Open On Rise (Normally Closed) |
| Open Temperature | TBD |
| Close Temperature | TBD |
| Mounting/Sensing | Clip / Pipe |
| Electrical Rating | 120/250VAC, 16 Amps, S.P.S.T. |
| Environmental | -4°F-392°F (-20°C-200°C) |
| Insulation Resistance | 100 MΩ (with a 500 VDC megger) |
| Circuit Resistance | 50mΩ or less |
| Dielectric Strength | 1480VAC/1 minute |
| Approvals | UL (E145478, XAPX2) c-UL (E145478, XAPX8) |
Resources
Moisture Resistant Thermostat Resources
SEO (T) Moisture Resistant Series Datasheet
Download Resource
